Audio CODEC '97
|
![](/images/blank.gif) |
|
![](../../../..//images/blank.gif) |
The CS4299 is an AC '97 2.1 compatible, stereo, audio CODEC designed for PC multimedia systems. Using the industry leading Delta-Sigma and mixed-signal technology, the CS4299 enables the design of PC 99-compliant desktop, portable, and entertainment PCs. Coupling the CS4299 with a PCI audio accelerator or core logic supporting the AC '97 interface, implements a cost-effective, superior quality, audio solution. The CS4299 surpasses PC 99 and AC '97 2.1 audio quality standards. Windows XP and 2000 drivers are available.
|
![](../../../..//images/blank.gif) |
Product Features
|
![](../../../..//images/blank.gif) |
- AC '97 2.1 compatible
- Meets or exceeds the Microsoft PC 99 audio performance requirements
- Industry leading mixed-signal technology
- 20-bit stereo DAC; 18-bit stereo ADC
- Sample rate converters
- Four analog, line-level, stereo inputs: LINE_IN, CD, VIDEO, and AUX
- Two analog, line-level, mono inputs: modem and internal PC beep
- Dual stereo, line-level outputs: LINE_OUT and ALT_LINE_OUT
- Dual microphone inputs
- High-quality, pseudo-differential CD input
- S/PDIF digital audio output
- 3D stereo enhancement
- Extensive power management support
- Package: 48-pin TQFP
|
