WinSSD Applications
WinSSD Loopback Test
WinSSD's Loopback Test allows functional testing of any serial port on the system, provided a loopback plug is present. WinSSD provides a pattern test, an ASCII test, and a modem control signal test. Multiple passes can be programmed to meet the user's requirements. Loopback plug diagrams are provided to aid in building loopback plugs.
![](../images/winssd_loopsm.gif)
Click on image for larger view. |
|
![](../images/greenline.gif)
WinSSD Applications
WinSSD BERT (Bit Error Rate Test)
Multithreaded bit error rate test application for verifying serial port performance. WinSSD's BERT test can be used in loopback or point-to-point test configuration. This software tracks bit errors and sync losses while displaying transmit and receive frame counts, the number of bytes verified, and driver error statistics.
![](../images/bert-small.gif)
Click on image for larger view. |
|
![](../images/greenline.gif)
WinSSD Applications
WinSSD Terminal
Terminal program provided as a sample application that allows characters to be echoed back to the screen. A Hex check box is provided to allow typed characters to be echoed along with their Hex equivalents.
![](../images/winssd_termsm.gif)
Click on image for larger view. |
|
![](../images/greenline.gif)
DOS - Serial Utility Disk
The Sealevel Serial Utility Disk provides the tools necessary to verify the installation and operation of Sealevel asynchronous serial I/O products in DOS and other non Windows Operating Systems. The Serial Utility Disk is included with each Sealevel asynchronous serial I/O adapter purchased.
Driver / Utility software on the disk includes:
- SeaCOM for DOS - Interrupt driven DOS serial port driver
- SSD - General asynchronous diagnostic utility for DOS
- SLT - Serial loopback test program
- PCSSD - PC Card (PCMCIA) Diagnostic Menu Driven Program
- SEAPC - PC Card (PCMCIA) Client Enabler
- SSEnable - PC Card (PCMCIA) Stand Alone Card Enable Program
|
