CS/EE 6710 Syllabus
Digital VLSI Design
Fall 2006



General Information


Important Information

q       College guidelines for adding, dropping, and other administrative issues can be found here.

q       Cheating will not be tolerated! A discussion of this issue can be found here

q       The University of Utah provides reasonable accommodation to the known disabilities of employees and students. If you need special accommodations, please let the instructor know at the beginning of the semester.


Course Description

This course introduces mask-level integrated circuit design for digital circuit design. Correct engineering design methodology is emphasized. Topics covered in lectures include:

q       CMOS processes

q       Mask layout methods and design rules

q       Circuit characterization and performance estimation

q       Standard cell design and use

q       Custom data path circuit design

q       Use of CAD tools for VLSI design

q       Design for testability

q       CMOS subsystem and system design.

This is a project-oriented course in which you will design a modest-sized CMOS integrated circuit. Except for the occasional tutorial session, no specific lab times are scheduled, and you can work at your convenience.

The homework assignments and the project will require the use of the workstations in the CADE lab (Cadence and Synopsys run only on Solaris and linux machines – not Windows). Students must have an account that will allow them to use the CADE machines, and some familiarity with UNIX and X-windows will be assumed.

Integrated circuit design is mastered only through experience. The homework, as well as lectures, will be closely tied to the term project, the design of a simple standard cell library and then the use of that library to design a project. The initial design of cells for the project will be done individually. You must complete the design of these cells on time. You are encouraged to interact with others, but until you are asked to form teams, the work on your cell designs, simulations, etc., must be your own.

The final library and project will be done in teams. The project must be completed, and you must submit a final report in the format specified.

Within the constraints of available funding, eligible projects will be fabricated through the MOSIS service. If your project is fabricated, it must be tested; you can get credit for testing it in CS/EE 6770 or as an independent study project. You are encouraged to enter your design in the DAC (Design Automation Conference) Student Design Contest.


Tutorials on the CAD tools

We'll be using CAD tools from Cadence and Synopsys this semester. These are "industrial strength" CAD tools and are the same tools that major chip makers use to build commercial chips. As such they are very powerful tools but they aren't necessarily intuitive to use. They are very efficient tools for the power user, but they sometimes have a steep learning curve.

I’m in the process of rewriting all the tool tutorials and putting them in book form as a CAD tool lab manual. Draft chapters will appear here as they are available. You are, of course, free to read the CAD tool documentation and learn more if you like. However, I encourage you to start with the tutorials because we know that using the tools in this way works. If you discover some new trick about using the tools, I’d love to hear about it!

The following draft book chapters are in PDF format…

q       Title page and table of contents

q       Chapter 1: Getting Started

q       Chapter 2: Cadence Design Framework

q       Chapter 3: Composer Schematic Capture

q       Chapter 4: Verilog Simulation

q       Chapter 5: Virtuoso Layout Editor

q       Chapter 6: Spectre Analog Simulation

q       Chapter 7: Cell Characterization

q       Chapter8: Verilog Synthesis

q       Chapter 9: Abstract Generation

q       Chapter 10: SOC Encounter Place and Route

q       Chapter 11: Chip Assembly

q       Chapter 12: Design Example: TinyMIPS

q       Appendix A: Tool Administration

q       Appendix B: Highlights of the Tools

q       Appendix C: Tool and Startup Scripts

q       Appendix D: MOSIS SCMOS Rev8 Design Rules

q       Appendix E: Technology and Cell Libraries

q       Bibliography and Index

q       A paper by Allen Tanner about the makemem memory generator

q       A tutorial demonstration of the makemem program generating a ROM and an SRAM


Assignments and Labs

The labs for this class are on a very tight schedule in order to complete the project by the end of the semester. Any slip in the schedule will cause lots of headaches later on! Students will need to be aware of the schedule and complete labs on time.

The lab contents will be available here as soon as we have them ready...

With CAD5 we're going to start electronic handin of much of the assignment. General instructions for the CADE handin process are located here. Instructions for each specific assignment will be either in the assignment or emailed to the class mailing list.

q       Review assignment. In PDF. This assignment will be graded! It will just be graded pass/fail though. If you can answer all the questions easily then you probably have the right background for this course. If you can't, you will need to brush up on some of your digital logic background! Please take this seriously! If you have trouble with this exam, you will also have trouble with the project! Due Friday, September 1st.

q       CAD1: in PDF - Cadence schematic capture and Verilog simulation. Reading: CAD Manual Chapters 1-4. Due Friday September 1st.

q       CAD2: in PDF - Virtuoso layout, DRC, LVS, Analog simulation. Reading CAD manual Chapters 5-6. Due Thursday September 14th.

q       CAD3: in PDF - FF/Register design. Reading: Lab Manual Chapters 3-6, Book Chapter 1 (section 1.4). Also peek ahead at Chapter 7. Due Thursday September 21st.

q       CAD4: in PDF - DC simulation, transistor operation. Reading: CAD manual Chapter 6, Book Chapter 2. Due Thursday September 28th.

q       CAD5: in PDF - Initial 5-cell Library. Group Assignment! Reading: CAD manual Chapters 7-8. Due Tuesday October 10th.
For CAD5 use electronic handin for your cell library project directory (UofU_6710Lib), your UofU_6710Lib.lib file, and any Verilog testbenches you used for simulating the cells. Also include a README file that explains what has been turned in. The behavioral and structural Verilog files that demonstrate using your library with Synopsys should be printed and turned in to the box outside the SoC office, along with your group number, names, and the user id under which the electronic files were handed in.

q       CAD6: in PDF - Seven more cells to make a 12-cell Library. Group Assignment! Reading: CAD manual Chapters 7-9. Due Tuesday October 17th.
For CAD6 use electronic handin for your cell library project directory (UofU_6710Lib), your UofU_6710Lib.lib, UofU_6710Lib.lef, and UofU_6710Lib.v files, and any Verilog testbenches that you used for simulating the cells. Also include a README file that explains what has been turned in. Your report on how you chose the extra cells to include in your library should be printed out and handed in in the box outside the SoC office. This report should include examples of using your new library on each of the four example Verilog files. Make sure to include your group number, names, and the ID under which the electronic handin files were handed in.

q       CAD7: in PDF - A few more cells, and place and route of a controller example. Reading: CAD manual Chapter 10. Due Tuesday October 24th.
Handin instructions are in the assignment.

q       Proposal: in PDF - Tell me about the project you plan to design. Due Thursday November 2nd.
You can print this assignment and put it in the box by the School of Computing office, or you can use electronic handin for the "Proposal" assignment.

q       You can find the charROM character ROM in the /uusoc/facility/cad_common/local/Cadence/lib/charROM directory. You can use the library manager to add this charROM library to the set of libraries that you can see. You can find a data sheet for the charROM here.

q       Example midterm in PDF - This is an example midterm exam from a previous version of this class. This year's midterm will have a similar structure, but (of course) with different questions!. The midterm will be in class on Tuesday November 21st.


Lecture Slides

I'll put the slides up here as they become available.

q       Slides for lecture 1: intro, CMOS transistors as switches. Available in PDF six to a page and in PDF two to a page, Reading: Chapter 1, sections 1.1-1.4


q       Slides from David Harris on transistor-level gate design. Available in PDF six to a page and in PDF two to a page, Reading: Chapter 1, Section 1.4.

q       Intro to Layout, Design Rules. Available in PDF six to a page and in PDF two to a page, Reading: Chapter 1, section 1.5 (and Chapter 6)

q        More Layout (NOR example), intro to Verilog testbenches. Available in PDF six to a page and in PDF two to a page, Reading: Verilog companion text, Verilog docuements linked from this class web site.

q        More detailed intro to Verilog testbenches. Available in PDF six to a page and in PDF two to a page, Reading: Verilog companion text, Verilog docuements linked from this class web site.

q        Even more Layout (line of diffusion layout, Euler diagrams, stick diagrams). Available in PDF six to a page and in PDF two to a page, Reading: Chapter 5, section 5.3 in particular

q        Slides from David Harris on the MIPS example in section 1.7. Available in PDF six to a page and in PDF two to a page

q        MOS Transistor Theory Available in PDF six to a page and in PDF two to a page, Reading: Chapter 2, 4.

q        CMOS processing and fabrication. Available in PDF six to a page and in PDF two to a page, Reading: Chapter 3

q        Logical Effort transistor sizing available in PDF six to a page and in PDF two to a page. Reading: Chapter one from Sutherland, Sproull, and Harris' book on Logic Effort is here in PDF.

q        Logical Effort slides from David Harris (the co-author of our textbook, and co-author of the Logical Effort book) available in PDF six to a page and in PDF two to a page. Reading: Chapter 4, Section 4.3.

q        Verilog for Synthesis. available in PDF six to a page and in PDF two to a page. Reading: CAD Manual Chapter 8, Textbook Appendix A.

q        Lightening tour of Design Compiler and SOC Encounter. available in PDF six to a page and in PDF two to a page. Reading: CAD Manual Chapters 8 and 10

q        Slides on the MIPS processor in the text. available in PDF six to a page and in PDF two to a page. Reading: Textbook Chapter 1 and Appendix A.10

q        Slides on datapath circuits. available in PDF six to a page and in PDF two to a page. Reading: Textbook Chapter 10

q        Slides on displays and VGA controllers. available in PDF six to a page and in PDF two to a page.
Last year the VGA controller was a CAD assignment for everyone. The assignment and specs for the assigned VGA controller from last year can be found herre. The specs and description may help you getting your own VGA controller to work. Note that the tutorials pointed to by last year's assignment aren't valid. You should be using our CAD Manual flow.

q        Slides on pads, pad frames, and finishing up. available in PDF six to a page and in PDF two to a page. Reading: Textbook Chapter 12 - section 12.1-12.4, section 8.9 (GDS)


Grading Policy

Grading will be based on participation. Expected participation includes:

o        Homework: Written homework will take the form of problem sets, project proposals, and other written work.

o        Labs: Labs involve mask-layout design of cells that will be used in your semester project. We will use CAD tools from Cadence runing on Solaris and linux.

o        Mid-term Exam: There will be one exam given sometime in the middle of the semester.

o        Class Project: The class project is the design of a small digital standard cell library and the use of that library to design a moderate-sized project. Each team will implement the baseline cell library, and propose additional circuits to tailor their library to a specific application area. Graduate projects (6000-level) will be required to be "more interesting" than the undergraduate projects. Graduate students will also be required to read and review two papers relating to VLSI from journals or conferences in the area. More details about this as class progresses. Project grading will be divided into two areas of importance. The first of these is design quality, which means soundness of engineering design (appropriate design trade-offs) and ingenuity at all levels of the design activity. This will be evaluated with equal weight placed on:

§         complexity: the number of extras added to the baseline library, and the complexity of the project built with the library.

§         application/systems decisions: evaluates whether intelligent decisions were made in making the design fit the application.

§         implementation quality: evaluated in three areas: datapath, chip-floorplan, and circuit design. Datapath evaluation will look at pitch-matching, over-cell routing, density, power routes, etc. Floorplanning will evaluate chip planning and how well things fit together. Circuit design will evaluate the quality of the custom transistor design.

§         completion: will look at how far the project progressed. Mask level LVS/DRC results will be looked at as well as simulation results and whether the chip is ready of MOSIS fabrication.

Note that ingenuity is usually seen in simplicity, rather than added complexity. Credit will be given for doing things the right way, rather than the easy way.

The second area is documentation. The final report should include an application-based specification and a clear description of your resulting chip implementation. The report must follow the format for an entry in the DAC Student Design Contest. An example will be given in class. No credit will be given for late reports. Each member of a project team will typically receive the same grade for the final project and for the project cell designs. If a particular group member is not contributing substantially to the project effort, his or her project grade and cell design grades will all be reduced by an appropriate percentage. Each group member will be given a peer contribution form to assess team member's efforts on each project-related assignment. These forms will be collected in the middle and at the end of the semester.

Percentages for grades are as follows:

§         Labs (cell designs) & Homework: 40%

§         Design Review: 5%

§         Mid-term Exam: 15%

§         Project (design and report) 40%


Helpful Information


General Information

q       Chapter one from Sutherland, Sproull, and Harris' book on Logic Effort is here in PDF. The website for the book is located here

q       A document by Eric Marsman from University of Michigan that describes a layout and floorplanning approach in a three metal process. This is a nice basic guide to planning interconnect issues. It's in PDF.

q       A guide to basic electronics including MOS transistors: Appendix B from Contemporary Logic Design by Randy Katz. You don't need to know the sections on bipolar or diode logic. The MOS section is the most important.

q       Errata (mistakes) in the class textbook,

q       The SCN3M_SUBM SCMOS design rules from MOSIS, translated to microns, in PDF format, and in Word format.

q       The official SCMOS Rev8 design rules at MOSIS

q       A link to Reid Harrison's CS/EE 5720/6720 Analog VLSI class. They are also using the NCSU CDK and the SCMOS rules so you can find more information here including tutorials on analog simulation of designs built with the NCSU CDK, and a layout tutorial.

q       Information on Chip Fabrication at USC Information Sciences Institute (ISI): MOSIS (MOS Implementation Service) home page

q       LaTeX style files for producing IEEE-formatted two-column papers: A .cls style file with formatting information, a .bst bibliography style file, and a sample .tex file that demonstrates how it all should be used.

q       A Microsoft Word example file that shows how to get an IEEE format in MS Word.

q       A data sheet on the HM6264 8kX8 SRAM from the DSL lab kits. This is a good example of a generic SRAM that shows read and write protocols.

q       Documentation from Tanner Research about their digital pads in PDF. We'll be using these pads for our chip designs.

q       A page from Americn Microsemiconductor that has lots of tutorials on various semiconductor topics.

q       Here's a paper that I wrote a few years ago that describes a simple stack based architecture similar to the transputer that might make a great project. Even if you don't use this exact architecture, stack-based machine make nice simple processor architectures for those wanting to do a processor project. You definitely don't have to do this as a self-timed processor! It's a perfectly good synchronous stack machine too.

q       Here are a couple papers from the Journal of Solid State Circuits about latches and flip flops. These are just a couple examples, there are lots of papers about this! These papers analyze different latch and flip flop circuits for speed and power performance.

o       Comparative Analysis of Master Slave Latches and Flip-Flops for High-Performance and Low-Power Systems by Vladimir Stojanovic and Vojin G. Oklobdzija

o       New single-Clock CMOS LAtches and Flipflops with Improved Speed and Power Savings by Jiren Yuan and Christer Svensson

q       Compact yet High-Performance (CyHP) Library for Short Time-to-Market with New Technologies by Nguyen Minh Duc and Takayasu Sakurai. This paper makes a case that a small (11 or 20 cells) library can perform almost as well as a 400 cell library when used with Synopsys design compiler and standard benchmarks.

Tool Information (Cadence, Synopsys, Verilog, etc. )

q       Here is a user's guide to the new XG mode of Synopsys design_compiler

q       Single-page reference sheet on Verilog syntax. This is the language used by the Verilog-XL simulator in Cadence. Use this as the equivalent of the ViewSim command language in Powerview. PDF format

q       A Verilog Quick Reference guide (in Postscript)

q       Another Verilog guide, this one is a lab from another class, but it talks about simulating Verilog code using the Verilog-XL simulator.

q       Yet another Verilog guide. This one is an intruduction to Verilog from Daniel C. Hyde at Bucknell University. This guide is targetted at simulation.

q       A set of documents from Synopsys that describe good Verilog coding style for synthesis. They are all in PDF. These files are linked together if you're using the Acroread plugin to netscape or IE. Open the Table of Contents and you should be able click on the chapters in that file to open up the chapters.

o       Table of contents

o       Chapter 1

o       Chapter 2

o       Chapter 3

o       Chapter 4

o       Chapter 5

q       A reference manual from Synopsys describing the Verilog synthesis engine.

o       Table of contents

o       Chapter 1

o       Chapter 2

o       Chapter 3

o       Chapter 4

o       Chapter 5

o       Chapter 6

o       Chapter 7

o       Chapter 8

o       Chapter 9

o       Chapter 10

o       Appendix A

o       Appendix B

q       Here's a directory that has all the help files for the Module Compiler Express cells

Project Information

q       Some project ideas in Word, in HTML and in PDF.

q       A description of the Instruction Set Architecture (ISA) of an example class processor. This is the description from the University of Michigan that describes the "simplified encoding."

q       Some slides from EECS 427 at Michigan about the two-stage pipeline of the class processor.

q       A CR16 lecture from CS/EE 3710 last year: Six per page, PDF This isn't quite exactly the same as the Michigan version, but it's close.

q       PDF version of CR16A Programmer's Reference Manual. This is the manual that describes in detail the operation of the real CR16, and Appendix A has the details of the "real encoding" should you want to use that for your project. Note that this document is 94 pages long...

q       Home page at National for a bunch of other CR16 documents. Note that we are more interested in the CR16A than in the CR16B, although they are very similar.

q       Information about the DAC student VLSI Design contest


Reference Material

q       David Hodges, Analysis and Design of Digital Integrated Circuits (3rd ed), McGraw Hill, 2004.

q       Wayne Wolf, Modern VLSI Design (3rd ed), Prentice Hall, 2002.

q       Jan M. Rabaey, Digital Integrated Circuits (2nd ed), Prentice Hall, 2003.

q       Glasser and Doberpuhl, The Design and Analysis of VLSI Circuits, (most detailed circuit treatment), Addison-Wesley, 1985.

q       Michael J. S. Smith, Application-Specific Integrated Circuits, (new, comprehensive, advanced level) Addison-Wesley, 1997.

q       Hodges and Jackson, Analysis and Design of Digital Integrated Circuits (Second Edition), McGraw-Hill, 1988.

q       Hennessy and Patterson, Computer Organization & Design - The Hardware/Software Interface, (3810 text) Morgan Kaufmann, 1994.

q       IEEE Journal of Solid-State Circuits I

q       EEE Trans. on Computer-Aided Design of Integrated Circuits and Systems

q       IEEE International Solid-State Circuits Conference, 1954 -

q       Advanced Research in VLSI, 1980-

q       IEEE Custom Integrated Circuits Conference, 1979 -

q       EE Times, Electronics, Computer Design, EDN...
