Customer Designs

This page lists a few examples of successful customer designs using Xilinx PCI.


Intel

"Fast development time and compliance to the 2.1 PCI specification are important."
An Intel proof-of-concept design incorporating the Xilinx LogiCORE PCI interface development kit is available as an application note at:
http://developer.intel.com/design/intarch/Internet Link

Mike Carboni
Technical Marketing Manger
Intel's Embedded Microcomputer Division


Click here to view

Management Graphics

"With Xilinx PCI LogiCORE product, we were able to achieve a sustained bandwidth of 124 Mbyte per second in our EDOX Document Server. The high performance of the LogiCORE solution combined with the short time to market and flexibility of a programmable FPGA solution, made Xilinx the obvious choice."

Tony Clark
R&D Manager
Management Graphics, Inc


Click here to view

Dome Imaging SystemsInternet Link

The Dome Imaging MX2/PCI board, which can handle transfers of over 500 MB/sec from the host, is the first in a new family of high resolution display controllers for the medical imaging market .

"With the Real 64/66 PCI products from Xilinx, we were able to implement a fully compliant PCI interface and other functions such as direct memory access (DMA), 4 dual-port FIFOs, and 200,000 gates of our own unique design in a single device. After evaluating different solutions in the market, we found that only Xilinx could meet the demanding requirements for full 66MHz PCI compliance."

John Beck
Principal Engineer
DOME Imaging, Inc.


Click here to view
