The SeaPORT PLC-16 provides 8 optically isolated inputs and 8 Form C relay outputs, which can be utilized for PC based control and industrial automation. The 8 Form C relays support 2 Amp switch and carry current. Our unique serial string naming feature allows multiple USB digital I/O devices to retain their specific identity within the system. Onboard removable screw terminals are provided to simplify wiring connections. A DIN rail mounting option is available.

Our SeaI/O Family of Windows 98/ME/2000/XP Software drivers is included along with sample applications and utilities for rapid application development.

Digital I/O 8 in / 8 Form C out Back to USB DIO

View The 8206 User Manual (PDF) Download The SeaI/O Drivers

• "Hot Swapping" / Auto Configuration

• 8 SPDT (single pole double throw) relays

• 1 eight bit optically isolated input port

• Optimized for 0-24 VAC/DC operation

• Onboard removable screw terminals

• Compatible with third party PC-based
  control programs

• Serial string allows individual device
  naming and configuration
