Overview Inventra TM, a Mentor Graphics business unit, offers an extensive list of synthesizable standard component, communications, multimedia, telecom, DSP, and computer connectivity cores to meet current and emerging design methodologies such as block-based design. Inventra also offers physical libraries and design services to enable designers to meet the challenges of increased design complexity and faster time-to-market. All Inventra products support EDA Tool, foundry and derivative design independence thereby offering the maximum degree of flexibility without the time and expense of internal development. The computer connectivity cores and products (Universal Serial Bus, PCI, Simulation Models, and Evaluation Board) are available as a result of the acquisition of CAE Technology in November 1996. Inventra's Universal Serial Bus (USB) is a full hardware/software solution that is comprised of: Synthesizable Logic Blocks (Verilog & VHDL) Simulation Models Evaluation Board Virtual Simulation Framework (VSF) The VSF is a hardware / software co-design solution. It provides a seamless link between the software and hardware teams during the ASIC and system design phases. AllianceCORE Products to view the PDF files below. The AllianceCORE Products Table shows AllianceCORE products available from Inventra. Adobe Acrobat versions of the datasheets for these can be downloaded from the table. Contact Mentor Graphics for pricing.

AllianceCORE Products Table
Product	Description
AllianceCORE Modules - Base Level Functions
Low-Speed USB Function Controller	1.5 Mbps function controller with microcontroller interface.
Full-Speed USB Function Controller	12 Mbps function controller with support for microcontroller and generic back-end interfaces
3-Port USB Hub Controller	Xilinx 3-port USB hub controller
Supporting Developing Tools
USB Function Board	A Xilinx FPGA-based prototyping board for developing USB-complaint peripherals.
USB Hub Evaluation Board	A Xilinx FPGA-based demo board for developing USB-complaint hubs.
USB Simulation Model	Simulates full Host, Hub, and Target Functions.

Additional Areas of Technical Expertise The following table of products demonstrates other areas of Inventra technical expertise. Xilinx and Inventra are in the process of evaluating these to determine which are suitable as AllianceCORE products. If you have a need for a specific product then contact your local Mentor Graphics sales office for information or availability.

Product	Functional Description	Gates
Standard Bus Interfaces
MPCMCIA1	PCMCIA PC Card Interface	2,500
M82365SL	PCMCIA Card Interface Controller	17,000
M8490	SCSI for 5380 Compatible Asynchronous SCSI Interfacing	1,500
M1284H	IEEE 1284 Host Parallel Port	6,500
MI2C	I2C Bus Interface	1,500
32 Bit PCI	32 Bit PCI Core	10,000
64 Bit PCI	64 Bit PCI Core	13,000
PCI Simulation	PCI Simulation Model	N/A
DSP Functions
DDS	Direct Digital Synthesizer	Note 1
M320C50	Very High Performance Digital Signal Processor	40,000
M320C25	High Performance Digital Signal Processor	25,000
FFT / IFFT	FFT / IFFT / Fast Convolver	Note 1
FIR	Linear Phase FIR Filter	Note 1
NCO	Numerically Controlled Oscillator	Note 1
Viterbi	Viterbi Encoder / Decoder	Note 1
Reed-Solomon	Reed-Solomon / BCH Decoder	Note 1
RS-IESS308	Intelsat IESS-308 Reed Solomon CODEC with Data Interleaver / Deinterleaver	Note 1
RS CODEC	Reed Solomon CODEC	Note 1
RS-DVB	DVB Compliant Reed Solomon CODEC	Note 1
RS-CDPD	CDPD Compliant Reed Solomon CODEC	Note 1
DCT	8x8 Discrete Cosine Transform (DCT)	Note 1
ADPCM-G726	ADPCM CODEC, Full Duplex-1 channel	Note 1
ADPCM-G726	ADPCM CODEC, Full Duplex-2 channel	Note 1
ADPCM-G726	ADPCM CODEC, Full Duplex-4 channel	Note 1
Communications and Networking
BRIM-CORE	I.430 Basic Rate Interface Module (ISDN S-Interface)	Note 1
E1-CORE	E1 Synchronous Framing Structure Core	Note 1
T1-CORE	T1 Synchronous Framing Structure Core	Note 1
LILAC	Linked List Access Controller (LILAC)	Note 1
REO	T1 / E1 Timeslot Recorder	Note 1
X.50	X.50 Multiplexing Interface	Note 1
HDLC-CORE	Single Channel HDLC Controller	Note 1
M79C960	Ethernet LAN Controller ISA Interface	15,000
ARCNET	ANSI / ATA 878.1 ARCNET Token Bus LAN	Note 1
Base-Level Functions
MFDC	High Performance PC Compatible Floppy Disk Controller System (82077SL)	10,500
M765A	Extended Features Floppy Disk Controller Core for FM and MFM Formats	9,500
MDDS24	Enhanced High Margin Floppy & Tape Data Separator for data rates to 2Mbit/s	1,300
M91C360	High Margin Floppy & Tape Data Separator for data rates to 1.25 Mbit/s	1,300
M91C36	High Margin Floppy Disk Data Separator for data rates to 1.25 Mbit/s	1,100
M80186	Industry Standard 16-Bit Microprocessor	30,000
M8086	Industry Standard 16-Bit Microprocessor	18,000
M8052	High Performance Industry Compatible 8-Bit Microcontroller, 3 timers, serial I/O	11,000
M8051	High Performance Industry Compatible 8-Bit Microcontroller, 2 timers, serial I/O	10,000
M8042	8-Bit Peripheral Interface Microcontroller with timer (Slave Microcontroller)	3,400
M8048	Compact Embedded Industry Compatible 8-Bit Microcontroller with Timer	3,400
MZ80	High Performance Industry Compatible 8-Bit Microprocessor	8,000
DMAxN	Multi Channel DMA Controller	Note 1
M82C206	Integrated Peripheral Controller	18,000
M8237A	General Purpose programmable four channel DMA Controller	3,700
M8254	Extended Features three channel Programmable Interval Timer (PIT)	3,000
M8253	General Purpose three channel Programmable Interval Timer (PIT)	3,000
M6845	General Purpose Programmable CRT Controller	2,600
M146818	Ultra Low Power Real Time Clock with up to 114 bytes of RAM	2,000
M8259A	Eight Channel Cascadable Programmable Interrupt Controller (PIC)	1,600
M8255	General Purpose Programmable Peripheral Interface	1,600
USART	Universal Synchronous / Asynchronous Receiver / Transmitter Core	Note 1
M85C30	Two Channel Enhanced Serial Communications Controller with FIFOs	16,500
M82530	Two Channel Advanced Serial Communications Controller	12,200
M16550A	Universal Asynchronous Receiver / Transmitter (UART) with FIFO	6,600
M8251A	Universal Synchronous / Asynchronous Receiver / Transmitter (USART)	2,200
M16C450	PC Compatible Universal Asynchronous Receiver / Transmitter (UART)	2,000
M8250B	PC Compatible Universal Asynchronous Receiver / Transmitter (UART)	2,000
M8868A	Compact Universal Asynchronous Receiver / Transmitter (UART)	760
M6402	Compact Universal Asynchronous Receiver / Transmitter (UART)	750
FISPbus	68000 MPM Micro Personality Module	Note 1
FISPbus	H8 Micro Personality Module	Note 1
FISPbus	SH Micro Personality Module	Note 1
FISPbus	ARM 7 Micro Personality Module	Note 1
FISPbus	8051 Micro Personality Module	Note 1
Notes:
1. Gate counts for these cores are application dependent. Contact Partner for more information.

---
